Description

– Brand : LEO
– Model :XKP1104
– Power Consumption : 1.5HP / 1100W
– Voltage : 220V (50Hz)
– Inlet – Outlet : 50mm
– Max Flow : 375L/min
– Max Head : 15m
– Max Suction : 3.5m
– Max.liquid temperature:+35℃
Size (length*width*height): 585mm x 220mm x 290mm

LEO XKP804E Swimming Pool Pump (800W/290Lmin/50mm) ID31156

– Brand : LEO
– Model :XKP804
– Power Consumption : 1.1HP / 800W
– Voltage : 220V (50Hz)
– Inlet – Outlet : 50mm
– Max Flow : 290L/min
– Max Head : 11m
– Max Suction : 3.5m
– Max.liquid temperature : +35℃

 Application:
– XKP series swimming pool pumps are self-priming centrifugal pumps (with filter)
– Mainly used in water circulation & filtration systems
– Small and medium pools
– Water treatment systems
– Landscape fountains
– Light industries.

Pump:
– Type – Pool Pump
– Special engineered plastic pump body
– Plastic impeller (Rotor)
– AISI 304 stainless steel shaft
– Max. liquid temp – 35*C

Motor:
– C&U bearing
– Motor with copper or aluminium winding
– Built-in thermal protector (Single Phase)
– Insulation class – F
– Protection class IPX5
